FLEXIBLE ROLLER CONVEYOR
Description
🔷 FLEXIBLE ROLLER CONVEYOR
Description:
The Flexible Roller Conveyor is a highly adaptable and space-saving material handling solution designed for temporary or dynamic operations. Featuring a scissor-style expandable frame and free-turning rollers, it can be easily extended, curved, and compressed to suit various layouts and applications. This conveyor is ideal for loading/unloading trucks, warehouse operations, and variable production areas.
Its mobility and modularity make it perfect for fast-paced logistics, e-commerce, and distribution centers where space and speed matter.
---
✅ Key Features:
🔹 Expandable & Flexible Layout: Adjusts in length and shape – straight, curved, or zig-zag
🔹 Gravity Powered: No motors—uses the weight of the goods for easy movement
🔹 Mobile Design: Mounted on swivel castor wheels with brakes for quick relocation
🔹 Durable Rollers: Steel, zinc-coated, or plastic rollers based on application
🔹 Quick Setup: No installation required—ready to use in minutes
---
⚙️ Technical Specifications:
📏 Length (Expanded): 3 to 12 meters (custom sizes available)
🔁 Roller Type: Steel / Zinc-plated / PVC
📦 Load Capacity: 50–80 kg/meter
🛞 Roller Pitch: 75 mm / 100 mm / 150 mm
🧱 Frame Material: Heavy-duty MS powder-coated or SS
📐 Adjustable Height: 600 mm to 1000 mm
---
🔧 Optional Features:
🔸 Side guides for product alignment
🔸 End stops for load control
🔸 Plastic rollers for light-duty or scratch-sensitive items
🔸 ESD-safe design for electronics
🔸 Flexible powered version with drive rollers (available on request)
---
🏭 Applications:
🚚 Truck & Container Loading/Unloading
🏢 Warehousing & Distribution
📦 E-commerce Fulfillment Centers
🧰 Assembly & Packing Lines
🛒 Retail & Backroom Material Handling
