FLEXIBLE GRAVITY ROLLER CONVEYOR
Description
🔷 FLEXIBLE GRAVITY ROLLER CONVEYOR
Description:
The Flexible Gravity Roller Conveyor is a highly versatile and portable material handling system designed for easy movement of cartons, boxes, and totes in dynamic work environments. Built with a scissor-type expandable frame and free-rolling steel or plastic rollers, this conveyor is ideal for temporary, adjustable, and space-saving operations.
It can be easily expanded, contracted, or curved to suit various layouts—perfect for loading/unloading trucks, packaging lines, and flexible assembly zones.
---
✅ Key Features:
🔹 Expandable & Retractable Design: Adjustable length and shape for flexible operations
🔹 Gravity Powered: No motor—uses product weight to move items
🔹 Swivel Castor Wheels: Equipped with lockable wheels for easy movement and positioning
🔹 Curvable Layout: Can be configured in straight, “S,” or curved patterns
🔹 Robust Construction: Strong scissor frame supports industrial usage
---
⚙️ Technical Specifications:
📏 Length: 2 to 10 meters (expandable/collapsible)
📦 Load Capacity: 40–80 kg/meter (based on roller and frame type)
🛞 Roller Type: Steel / PVC / Zinc-coated
🔧 Roller Pitch: 75 mm / 100 mm / 150 mm
🧱 Frame Material: Heavy-duty MS powder-coated or SS
📐 Adjustable Height: 600 mm to 1000 mm (with locking mechanism)
---
🔧 Optional Features:
🔸 Side guides for product alignment
🔸 End stops or product stoppers
🔸 Trolley-based storage
🔸 Anti-static or plastic rollers for sensitive materials
🔸 Custom roller diameter for lightweight/heavy products
---
🏭 Applications:
🚚 Truck & Container Loading/Unloading
📦 Warehousing & Distribution Centers
🏭 Packing & Sorting Lines
🧰 Flexible Assembly Stations
🛍️ Retail, Courier, and E-commerce Hubs
