🔷 MOTORIZED ROLLER CONVEYOR Description: The Motorized Roller Conveyor is a modern, energy-efficient material handling system that uses integrated motorized rollers (MDR) to transport goods smoothly and reliably. Unlike traditional conveyors driven by external motors and chains, each zone or section in an MDR system contains its own motorized roller, offering precise control, quiet operation, and modular scalability. It is ideal for automated warehouses, packaging lines, order picking zones, and light-to-medium-duty assembly operations, especially where smart, sensor-based movement is needed. --- ✅ Key Features: 🔹 Built-in Motor Rollers: Each zone powered independently, improving control and energy efficiency 🔹 Low Noise & Maintenance: No external chains or belts—clean, quiet, and reliable operation 🔹 Modular & Scalable: Easily expandable, reconfigurable, and integrable with smart systems 🔹 Energy-Efficient: Power only runs when product is detected, saving energy 🔹 Safety First: Low-voltage operation (typically 24V DC), safe for human interaction zones --- ⚙️ Technical Specifications: 📏 Roller Diameter: 50 mm to 60 mm (typical) 📦 Load Capacity: Up to 50 kg per roller zone ⏩ Speed: 10–60 m/min (VFD or logic-controlled) ⚡ Power Supply: 24V DC or 48V DC (via power supply unit) 🧱 Frame Material: MS powder-coated / SS / Aluminum profile ⚙️ Control System: Integrated logic, PLC, or Ethernet-based for automation --- 🔧 Optional Features: 🔸 Zero pressure accumulation (ZPA) logic 🔸 Photoelectric sensors for zone control 🔸 Diverters, pushers, or stoppers for sorting 🔸 Touchscreen HMI with speed and direction control 🔸 ESD-safe rollers for electronics handling --- 🏭 Applications: 📦 Warehouse & Distribution Centers (WMS Integrated) 🛒 E-commerce & Order Fulfillment 🧰 Electronics & Appliance Assembly Lines 🏭 Automotive & Light Manufacturing Units 🧴 FMCG & Pharmaceutical Packaging Zones

🔷 POWERED ROLLER CONVEYOR Description: The Powered Roller Conveyor is a robust and efficient material handling system designed to automatically move products along a production or assembly line using motor-driven rollers. Ideal for transporting cartons, totes, pallets, and boxes, this conveyor offers smooth and controlled movement, reducing manual labor and increasing throughput in warehouses and industrial environments. With options like zone control, accumulation, and variable speeds, it is perfect for modern, automated logistics and manufacturing systems. Key Features: 🔹 Motor-Driven Rollers (MDR): Each zone powered individually for energy efficiency and control. 🔹 Smooth & Quiet Operation: Precision engineering for low noise and vibration. 🔹 Modular Design: Easily extendable, reconfigurable, and integratable into existing systems. 🔹 Smart Controls: Optional sensors, PLC, and logic-based start/stop for product tracking and flow control. 🔹 High Load Handling: Suitable for medium to heavy-duty applications. Technical Specifications: 📦 Load Capacity: 50 kg to 1000 kg per meter (based on roller specs) 📏 Roller Diameter: 38 mm to 89 mm 🌀 Roller Pitch: 75 mm to 150 mm ⚙️ Drive Type: Motorized rollers / chain-driven rollers / belt under rollers ⚡ Power Supply: 24V DC / 230–415V AC (depending on motor type) 🧱 Frame Material: MS powder-coated / SS304 / Aluminum Optional Features: 🔸 Photoelectric sensors for accumulation 🔸 Pneumatic or electric diverters for sorting 🔸 Side guides and product stoppers 🔸 Integration with WMS/PLC/HMI systems 🔸 Curved or angled roller segments Applications: 📦 Warehousing & E-commerce Order Fulfillment 🏭 Automotive and Assembly Lines 🧴 Pharmaceutical and FMCG Packaging 🛠️ Manufacturing and Sorting Stations 🚛 Loading/Unloading Automation

Motorized Roller Conveyor – Efficient, Reliable, and Smart Material Handling Our Motorized Roller Conveyor is a cutting-edge solution designed to optimize material movement in warehouses, manufacturing units, and distribution centers. Engineered for high performance and low maintenance, this conveyor system features powered rollers that ensure smooth, consistent flow of goods with minimal human intervention. Equipped with advanced drive mechanisms and customizable roller spacing, the system is ideal for handling various load sizes — from cartons and totes to heavy packages. Whether you're moving lightweight boxes or bulky goods, the motorized rollers deliver controlled, quiet, and energy-efficient transport. What sets our conveyor apart is its modular design, allowing easy integration with sensors, diverters, and control systems for automation-ready operation. With speed adjustability and zero-pressure accumulation options, it enhances productivity while protecting products from collisions and damage. Perfect for e-commerce, food & beverage, automotive, and logistics industries, this solution reduces labor costs, increases throughput, and streamlines workflow with minimal downtime. Product Details: Minimum Order Quantity: 10 Meter Roller Material: Steel Brand: IC Length: 10 feet to 100 feet Roller Diameter: 50 mm to 90 mm OD Usage/Application: Pallet Moving, Carton Box Width Available: 300 to 1500 mm Color: Customized Material: MS & SS Design: Customized Country of Origin: Made in India Additional Information: Production Capacity: 100 mtrs Delivery Time: 6 weeks

Telescopic Belt Conveyor System The 20 Feet Telescopic Belt Conveyor (TBC) accomplishes all Necessaries for comfortable and effective loading and unloading. All kinds of loose goods or unit loads (cartons, packages, all Conveyor able product) in or out of loading vehicles like trucks, Trailers, vans, containers. Receiving and dispatching at warehouse/distribution centers, Manufacturing and transportation companies. There is always a 20 Feet Telescopic Belt Conveyor that can do The work more quickly, more efficiently and less expensively than Traditional materials handling systems. 20 Feet Telescopic conveyors extends deep into the vehicle, Saving time and energy for loading. It has the extra leveling Feature which helps lifting the bags on top. The model choice is Mostly dependent on the size of the vehicle to be loaded and also The size of the pieces being conveyed. Its versatility can be gauged by the fact the belt can run in either Direction making it useful for loading and unloading operations. The machine comes with additional features like a) 360 degrees Bottom swivel angle to make it operate at different places or in Places where there are two loading bays. b) Castor wheel Mounting for easy mobility

🚀 Flat Belt Conveyor with Sensors – Smart Material Handling Upgrade your automation process with our Flat Belt Conveyor integrated with smart sensors — built for speed, accuracy, and intelligent control. This system not only moves your products efficiently but also detects, counts, and tracks them using advanced sensor technology. Whether you're in packaging, sorting, inspection, or assembly, this conveyor helps reduce manual work and increases productivity. Its sleek, flat surface and durable PU/PVC belt ensure smooth transport of materials, while photoelectric, proximity, or load sensors can be installed as per application needs. --- 🔑 Highlights: Compact and low-noise design Integrated sensors for object detection, counting, or sorting Customizable length, width, and speed Sensor types: Photoelectric, Infrared, Proximity, or Load sensors Supports automation with PLC or microcontroller integration Ideal for electronics, pharma, food processing, and packaging lines --- 📦 Applications: Detecting and rejecting defective parts Automatic part counting Box or carton movement tracking Machine infeed/outfeed automation Robotic pick & place synchronization --- Enhance your production line with intelligence and efficiency. Contact us to customize your Flat Belt Conveyor with Sensors today.

🔷 SPIRAL GRAVITY FREE FLOW ROLLER CONVEYOR Description: The Spiral Gravity Free Flow Roller Conveyor is a space-saving and cost-effective solution for downward vertical product movement using gravity. Designed with angled spiral rollers, it allows cartons, totes, and boxes to move smoothly and continuously from one floor to another without the need for power or motors. Its compact spiral structure makes it ideal for facilities with limited floor space and high vertical transport needs. Commonly used in warehousing, dispatch zones, retail logistics, and packaging lines, this conveyor enhances workflow and reduces manual handling. --- ✅ Key Features: 🔹 No Power Required: Operates entirely by gravity for energy savings 🔹 Spiral Design: Enables vertical movement while saving horizontal floor space 🔹 Smooth & Controlled Flow: Precision-angled rollers ensure safe, continuous descent 🔹 Modular & Scalable: Can be integrated into any material handling system 🔹 Low Maintenance: Simple design with minimal wear-and-tear components --- ⚙️ Technical Specifications: 📏 Height: 2 to 6 meters (customizable) 🔄 Roller Type: Zinc-plated steel / PVC / Rubber-coated 📦 Load Capacity: Up to 40 kg per unit (depending on product and pitch) 🌀 Roller Pitch: 75 mm / 100 mm / 150 mm 🧱 Frame Material: MS powder-coated / SS304 / Aluminum 📐 Spiral Slope: Typically 12°–18°, adjustable based on product type --- 🔧 Optional Features: 🔸 Entry/Exit transition rollers 🔸 Product guides or side guards 🔸 Adjustable legs or supports 🔸 Lockable castor base (for movable systems) 🔸 Safety stops or speed controllers --- 🏭 Applications: 📦 Carton and Tote Movement Between Floors 🏢 Multi-level Warehousing & Dispatch Systems 🧃 FMCG and Food Product Transfer 🛍️ Retail and E-commerce Fulfillment Centers 🏭 Assembly and Packaging Outfeed

🔷 POWERED SPIRAL CONVEYOR Description: The Powered Spiral Conveyor is a continuous-flow vertical conveyor designed to move products up or down between multiple levels within a facility, using motor-driven rollers or belts. Unlike traditional elevators or lifts, this conveyor offers non-stop, high-speed movement in a compact, space-saving spiral design. It is ideal for medium to high-throughput operations in industries like e-commerce, warehousing, food, pharma, and manufacturing. This system improves material flow and reduces floor space usage while maintaining excellent product control and reliability. --- ✅ Key Features: 🔹 Continuous Powered Movement: Ideal for moving items upward or downward without interruption 🔹 Space-Saving Spiral Design: Vertical transport in a minimal floor area 🔹 Smooth Product Handling: Suitable for cartons, totes, trays, and pouches 🔹 Energy-Efficient Drive: Geared motor or drum motor options 🔹 High Throughput: Handles large volumes with controlled speed and precision --- ⚙️ Technical Specifications: 📏 Height Range: 2 to 8 meters (customizable) 🔁 Conveyor Type: Powered rollers or modular belt 📦 Load Capacity: Up to 50 kg/unit (varies by design) ⏩ Speed: 10 to 60 meters/min (adjustable with VFD) 🧱 Frame Material: MS powder-coated / SS304 / Aluminum ⚙️ Drive System: Central motor drive with friction rollers or belts ⚡ Power Supply: 3-phase, 415V AC --- 🔧 Optional Features: 🔸 Entry/Exit conveyors for integration 🔸 Product guides and lane dividers 🔸 Multi-level transfer points 🔸 Safety covers and emergency stop switches 🔸 PLC + HMI control system --- 🏭 Applications: 📦 Warehouse Order Picking & Sorting 🛒 E-commerce Distribution Centers 🏭 Manufacturing & Assembly Lines 🧃 Food, Beverage, and FMCG Packaging 📤 Multi-floor Loading/Unloading Systems

🔷 FLAT BELT CONVEYOR Description: The Flat Belt Conveyor is one of the most commonly used and versatile material handling systems, ideal for horizontal or slightly inclined transport of products across various industries. It features a continuous flat belt, typically made of PVC, PU, or rubber, that moves over a frame supported by pulleys or rollers. This conveyor is perfect for light to medium-duty applications requiring smooth, efficient, and reliable product transfer. --- ✅ Key Features: 🔹 Simple & Versatile Design: Suitable for a wide range of materials and industries 🔹 Smooth Product Flow: Ideal for stable, consistent movement of items 🔹 Various Belt Types: Available in anti-static, food-grade, rough-top, or heat-resistant options 🔹 Compact Footprint: Easy to install, integrate, and relocate 🔹 Low Noise Operation: Ensures a quiet working environment --- ⚙️ Technical Specifications: 📏 Belt Width: 100 mm to 1200 mm (customizable) 📦 Load Capacity: Up to 100 kg/meter (varies by application) ⏩ Speed: 5 to 40 m/min (adjustable with VFD) ⛓️ Belt Material: PVC / PU / Rubber / Silicon 🧱 Frame Material: MS powder-coated / SS304 / Aluminum profile ⚙️ Drive Type: Center / End drive with geared motor ⚡ Power Supply: 230V/415V AC --- 🔧 Optional Features: 🔸 Side guides and product stoppers 🔸 Adjustable height stands 🔸 Sensors for auto start/stop 🔸 Inclined models with grip belts 🔸 Trolley-mounted or mobile base --- 🏭 Applications: 📦 Packaging and Inspection Lines 🏭 Assembly & Production Lines 🧃 Food & Beverage Handling 📄 Printing & Paper Industry 🔌 Electronics & Light Manufacturing 🛍️ Retail and Sorting Systems

🔷 FLEXIBLE ROLLER CONVEYOR Description: The Flexible Roller Conveyor is a highly adaptable and space-saving material handling solution designed for temporary or dynamic operations. Featuring a scissor-style expandable frame and free-turning rollers, it can be easily extended, curved, and compressed to suit various layouts and applications. This conveyor is ideal for loading/unloading trucks, warehouse operations, and variable production areas. Its mobility and modularity make it perfect for fast-paced logistics, e-commerce, and distribution centers where space and speed matter. --- ✅ Key Features: 🔹 Expandable & Flexible Layout: Adjusts in length and shape – straight, curved, or zig-zag 🔹 Gravity Powered: No motors—uses the weight of the goods for easy movement 🔹 Mobile Design: Mounted on swivel castor wheels with brakes for quick relocation 🔹 Durable Rollers: Steel, zinc-coated, or plastic rollers based on application 🔹 Quick Setup: No installation required—ready to use in minutes --- ⚙️ Technical Specifications: 📏 Length (Expanded): 3 to 12 meters (custom sizes available) 🔁 Roller Type: Steel / Zinc-plated / PVC 📦 Load Capacity: 50–80 kg/meter 🛞 Roller Pitch: 75 mm / 100 mm / 150 mm 🧱 Frame Material: Heavy-duty MS powder-coated or SS 📐 Adjustable Height: 600 mm to 1000 mm --- 🔧 Optional Features: 🔸 Side guides for product alignment 🔸 End stops for load control 🔸 Plastic rollers for light-duty or scratch-sensitive items 🔸 ESD-safe design for electronics 🔸 Flexible powered version with drive rollers (available on request) --- 🏭 Applications: 🚚 Truck & Container Loading/Unloading 🏢 Warehousing & Distribution 📦 E-commerce Fulfillment Centers 🧰 Assembly & Packing Lines 🛒 Retail & Backroom Material Handling
